Shenzhen Chimee Technology Co., Limtted

Panel Size(Diagonal)	46 inch
Display Area(HxV)	1018.08mm x 572.67mm
Outline Dimension(HxV)	1076.5mm x 634.7mm
Display Colors	16.7M
Resolution	1920 x 1080
Pixel Pitch	0.53025 x 0.53025
Contrast Ratio	4000:1
Brightness(cd/m2)	450
Responsive Time	6ms
Viewing Angle(H/V)	178°/178°
Life Time(minimum)	50,000 hours

Touch screen Size	46 inch
Touch Points	Detects up to 32 points
Touch technology	IR/ Touch Cell Imaging
Touch Method	Finger, gloved hand or other pointer.
Luminous Transmission	Better than 98% with glass
Touch Activation	No Pressure required
Finger Touch accuracy	± 1.5mm
Touch Durability	Unlimited
Touch response time	7~12 ms
Operating temperature	0~55℃
Operation humidity	10%~90%
Interface	USB2.0 Full speed
OS	Windows 2000, XP, VISTA, WINDOWS 7

	Solution1	Solution2	Solution3	Solution4
CPU	Intel Atom D525, Dual Core, 1.8Ghz, 1M cache, 45nm Technology	Intel Core i3-2100, 3.1Ghz, 3M Cache, Dual Core, Quad Threads	Intel Core i5-2300, 2.8Ghz, 6M Cache, Quad Core, Quad Threads	Intel Core i7-2600, 3.4Ghz, 8M Cache, Quad Core, 8 Threads
Chipset	Intel NM10 + nVidia ION2	Intel H61 Express	Intel H61 Express	Intel H61 Express
RAM	2G DDR III/1333	DDR III/4G/1333/Up to 16G	DDR III/4G/1333/Up to 16G	DDR III/4G/1333/Up to 16G
HDD	2.5 inch 320G SATA II/SSD from 16G	2.5 inch 320G SATA II/SSD from 16G	2.5 inch 320G SATA II/SSD from 16G	2.5 inch 320G SATA II/SSD from 16G
ODD	DVD/RW/Blue-Ray(Optional)	DVD/RW/Blue-Ray(Optional)	DVD/RW/Blue-Ray(Optional)	DVD/RW/Blue-Ray(Optional)
Audio	HD 8 Channel 7.1 Audio Sub-system	Realtek ALC889 HD(7.1) 8 Channel Codec System	Realtek ALC889 HD(7.1) 8 Channel Codec System	Realtek ALC889 HD(7.1) 8 Channel Codec System
Graphics	nVidia GT 218 integrated/ Full HD 1080P supported	Integrated with CPU or Add-on a dedicated physical Graphics card	Integrated with CPU or Add-on a dedicated physical Graphics card	Integrated with CPU or Add-on a dedicated physical Graphics card
Network interface card	10/100/1000M Gigabyte Ethernet Cotroller	Realtek 8111E 10/100/1000 Gigabyte Ethernet Controller	Realtek 8111E 10/100/1000 Gigabyte Ethernet Controller	Realtek 8111E 10/100/1000 Gigabyte Ethernet Controller
WiFi	150M High Quality WiFi Integrated	150M High Quality WiFi Integrated	150M High Quality WiFi Integrated	150M High Quality WiFi Integrated
Speaker	2 x 5w/10w Built-in Stereo Speakers	2 x5w/10w Built-in Stereo Speakers	2 x5w/10w Built-in Stereo Speakers	2 x5w/10w Built-in Stereo Speakers
Mouse/Keyboard	Wired/Wireless Keyboard(Optional)	Wired/Wireless Keyboard(Optional)	Wired/Wireless Keyboard(Optional)	Wired/Wireless Keyboard(Optional)
OS	Windows XP/Vista/7/Fedora/Ubuntu(Optional)	Windows XP/Vista/7/Fedora/Ubuntu(Optional)	Windows XP/Vista/7/Fedora/Ubuntu(Optional)	Windows XP/Vista/7/Fedora/Ubuntu(Optional)

1.Class A+ grade 335 standard full new and original factory packing LCD screen, brand for SAMSUNG, LG, CMO ,AUO, Toshiba, Sharp, etc.

2.High-class metal material frame, the color can be customized.

3.Ultrathin, high light, perfectly clear acrylic board or tempered glass on the surface of the LCD screen to protect the screen being damaged.

4.IR Motion Sensor can be customized.

5.Build-in anti-thief system included.

6.Floor standing type can be fixed on the ground by screws.

Business Organizations	supermarket, shopping malls, exclusive agency, chain shops, large-scale sales, hotels, restaurants, travel agencies, etc.
Financial Organizations	Banks, negotiable securities, funds, insurance companies, pawnshops, etc.
Non-profit Organizations	Telecommunications, post offices, hospital, schools, etc.
Public Places	subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers, etc.
Real Estate Property	Apartments, offices, commercial buildings, model rooms, property brokers, etc.
Entertainments	Movie theaters, fitness halls, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course, etc.

1.Color can be customized.

2.Dimension can be customized.

3.Can print Logo on the frame.

4.Can customize the design.

5.Hardware can be customized.
